Bộ lưu điện UPS APC BX2200MI-MS | 2200VA, 230V, AVR, 4 universal outlets
6,299,000
Xuất xứ | Brand New 100%, Hàng Phân Phối Chính Hãng, Bảo Hành Toàn Quốc |
Bảo hành | 24 tháng |
VAT | Đã bao gồm VAT |
Main Input Voltage | 230 V |
---|---|
Other Input Voltage | 220 V 240 V |
Main Output Voltage | 230 V |
Other Output Voltage | 220 V 240 V |
Rated power in W | 1800 W |
Rated power in VA | 2000 VA |
Input Connection Type | IEC 60320 C14 |
output connection type | 4 IEC 60320 C13 |
Number of rack unit | 2U |
Cable length | 1.5 m |
Number of cables | 1 |
Provided equipment | 1 IEC 60320 C13 to Schuko power cable 1 IEC 60320 C13 to C14 power cable 1 USB cable 1 RS-232 configuration cable 1 rack mounting brackets 1 rack mounting support rails user manual |
Thời gian chạy | View Runtime Graph
|
---|---|
Hiệu suất | View Efficiency Graph
|
Battery type | Lead-acid battery |
Battery voltage | 48 V |
Number of battery filled slots | 0 |
Number of battery free slots | 0 |
Battery recharge time | 4 h |
Battery life | 3…5 year(s) |
Replacement battery | APCRBCV201
|
Battery charger power | 70 W rated |
Max runtime | 3 min |
---|---|
Number of power module filled slots | 0 |
Number of power module free slots | 0 |
Redundant | No |
Colour | Black (RAL 7010) |
---|---|
height | 8.6 cm |
Width | 43.8 cm |
Depth | 46.2 cm |
Net weight | 18.8 kg |
Mounting location | Front |
Mounting preference | Lower |
Mounting mode | Rack-mounted |
USB compatible | Yes |
Mounting position | Horizontal |
Input voltage limits | 110...285 V half load 180...285 V full load |
---|---|
Network frequency | 40...70 Hz auto sensing |
Maximum configurable power in VA | 2000 VA |
---|---|
Maximum configurable power in W | 1800 W |
Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
Harmonic distortion | 3 % |
UPS type | Double conversion online |
Wave type | Sine wave |
Efficiency | 88 % (full load) |
Additional information | Configurable for 220 : 230 or 240 nominal output voltage |
bypass type | Internal bypass (automatic and manual) |
Crest factor | 3 : 1 |
product certifications | CE UKCA TISI |
---|---|
Standards | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
ambient air temperature for operation | 0…40 °C |
---|---|
Relative humidity | 0…95 % non-condensing |
Operating altitude | 0...3000 m |
Ambient air temperature for storage | -20…50 °C |
Storage Relative Humidity | 0…95 % non-condensing |
Storage altitude | 0…15000 m |
Acoustic level | 50 dBA |
Heat dissipation | 759 Btu/h |
IP degree of protection | IP20 |
Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
---|---|
Free slots | 1 |
control panel | Multifunction LCD status and control console |
Surge energy rate | 945 J |
---|
Unit Type of Package 1 | PCE |
---|---|
Number of Units in Package 1 | 1 |
Package 1 Height | 21.8 cm |
Package 1 Width | 70 cm |
Package 1 Length | 55 cm |
Package 1 Weight | 22.5 kg |
