PERFORMANCE |
|
Processor |
Intel® Core™ i3-13100, 4C (4P + 0E) / 8T, P-core 3.4 / 4.5GHz, 12MB |
Graphics |
Integrated Intel® UHD Graphics 730 |
Chipset |
Intel® B660 Chipset |
Memory |
1x 8GB UDIMM DDR4-3200 |
Memory Slots |
Two DDR4 UDIMM slots, dual-channel capable |
Max Memory |
Up to 64GB DDR4-3200 |
Storage |
512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® |
Storage Support |
Up to two drives, 1x 3.5" HDD + 1x M.2 SSD • 3.5" HDD up to 2TB • M.2 SSD up to 1TB |
Audio Chip |
High Definition (HD) Audio, Realtek® ALC623-CG codec |
Speakers |
1Wx1 |
Power Supply |
180W 85% |
Keyboard |
USB Calliope Keyboard, Black, English |
Mouse |
USB Calliope Mouse, Black |
Expansion Slots |
· One PCIe® 4.0 x16, low-profie (length < 167.65mm, height < 68.90mm) · One PCIe® 3.0 x1, low-profie (length < 167.65mm, height < 68.90mm) · Two M.2 slots (one for WLAN, one for SSD) |
Case Color |
Black |
Form Factor |
SFF (7.4L) |
Dimensions (WxDxH) |
100 x 308 x 274.8 mm (3.9 x 12.1 x 10.8 inches) |
Weight |
Around 4.5 kg (9.9 lbs) |
CONNECTIVITY |
|
Ethernet |
Integrated 100/1000M |
WLAN + Bluetooth |
Intel® Wi-Fi® 6 AX201, 802.11ax 2x2 + BT5.1 |
Front Ports |
· 1x USB-C® 3.2 Gen 1 (support data transfer and 5V@3A charging) · 2x USB 3.2 Gen 1 · 1x headphone / microphone combo jack (3.5mm) · 1x microphone (3.5mm) |
Rear Ports |
· 2x USB 2.0 · 2x USB 3.2 Gen 1 (one supports Smart Power On) · 1x HDMI® 2.1 TMDS · 1x DisplayPort™ 1.4 · 1x VGA · 1x Ethernet (RJ-45) · 1x line-out (3.5mm) |
SECURITY & PRIVACY |
|
Security Chip |
Discrete TPM 2.0, TCG certified |
Physical Locks |
· Smart Cable Clip · Kensington® Security Slot™, 3 x 7 mm · Padlock Loop |
Smart Cable Clip |
Smart Cable Clip |
MANAGEABILITY |
|
System Management |
Non-vPro® |
SERVICE |
|
Base Warranty |
1-year, Courier or Carry-in |
Included Upgrade |
1Y Premier Support Upgrade from 1Y Courier/Carry-in |
SOFTWARE |
|
Operating System |
None |
Bảo hành | 12 tháng |
VAT | Đã bao gồm VAT |
