– Công suất bộ lưu điện: 2000VA/ 1800W
– Công nghệ: Online (Double Conversion)
– Hệ số công suất: 0.8
– Điện áp vào: 190 – 280VAC
– Tần số ngõ vào: 40 – 70 Hz
– Điện áp ngõ ra: 208, 220, 230, 240VAC (Configurable)
– Dạng sóng ngõ ra: Sóng sin chuẩn
– Tần số ngõ ra: 50Hz/60Hz ± 0.5%
– Ắc quy: 12V/ 9AH
– Thời gian sạc pin: 5 giờ
– Thay thế pin nóng
– Màn hình hiển thị LCD và LED (xoay được 90 độ)
– Bảo vệ chống sét lan truyền: RJ11/ RJ45
– Emergency Power Off (EPO)
– Hỗ trợ phần mềm quản lý: PowerPanel® Business
– Hỗ trợ cổng kết nối: RS232, USB
– Hỗ trợ quản lý phần mềm từ xa: SNMP/ HTTP
– Kiểu dáng: Rack 2U hoặc Tower
Đặc tính kỹ thuật
Model |
OLS2000ERT2U |
Capacity (VA/W) |
2000VA / 1800W |
Typology |
Online (Double Conversion) |
Energy-Saving Technology |
Yes, ECO Mode Efficiency > 95% |
Input |
|
Input Type |
IEC C20 |
Frequency Range |
40~70Hz |
Output |
|
UPS Outlets (Numbers) |
(4+4) IEC C13 |
On Battery Output Voltage |
Pure Sine Wave at 208, 220, 230, 240 Vac (Configurable) |
On Battery Output Voltage Distortion (@Nominal Battery Voltage) |
≤ 3% (Linear Load), ≤ 5%(Non-Linear Load) |
On Battery Output Frequency |
50 Hz/ 60 Hz (Auto-Sensing or Configurable) ± 0.5% |
Transfer Time (Typical) |
0ms |
Overload Protection |
AC Mode: Warning only @ 110%>Load>105%, Transfer to bypass after 60sec @ 120%>Load>110%, Transfer to bypass immediately@ Load>120% Battery Mode: Warning only @ 110%>Load>105%, Shutdown after 10sec @ 120%>Load>110%, Shutdown immediately @ Load>120 |
Short Circuit Protection |
UPS Output Cut off Immediately or Circuit Breaker Protection |
Surge Protection and Filtering |
|
Surge Protection |
Yes |
DSL/Phone/Fax/Modem protection |
RJ11/RJ45 (One In/One Out) |
Battery |
|
Sealed Maintenance Free Lead Acid Battery |
(6) 12V / 7AH |
Typical Recharge Time |
5 |
Runtimes |
|
Half load-Full load (mins) |
16/6 |
Status Indication |
|
Indicators |
Power On, Line Mode, Battery Mode, Bypass Mode, ECO Mode,C/F Mode, Fault, Replace Battery |
Audible Alarms |
Battery Mode, Battery Low, Overload, UPS Fault, Replace Battery |
Communication |
|
Power Management Software |
PowerPanel® Business Edition |
Management |
|
Self-Test |
Yes |
Auto-Charge/Auto-Restart |
Yes |
Auto-Overload Recovery |
Yes |
Cold Start(DC Start) |
Yes |
Connectivity Ports |
(1) Serial Port (RS232), (1) USB Port, (1) EPO/ROO |
SNMP/HTTP Capable |
Optional |
Dimensions |
88 x 438 x 610 mm |
Weight |
21.2 kg |
Bảo hành | 24 tháng |
VAT | Đã bao gồm VAT |
