• Wireless Standard
  • IEEE 802.11 b/g/n
• Wireless Transfer Rate
  • Transmit: 300 Mbps*
  • Receive: 300 Mbps*
• Wireless Security
  • 64/128 bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK
• WLAN Features
  • AP mode
  • WDS
  • WISP mode
  • Wi-Fi Protected Setup (WPS)
  • Wi-Fi Multimedia (WMM)
  • Wireless scheduling
  • Wireless output power management
  • MAC address filtering
  • Auto channel selection
• Routing
  • NAT
  • Static IP, DHCP, PPPoE, PPTP, L2TP
  • DHCP server/client
  • IGMP v1/v2
  • Dynamic DNS
  • Bandwidth management
  • Protocol-based QoS
  • Auto-IP change mode
  • Auto-bridge mode
• VPN Pass-through
  • IPSec
  • PPTP
  • L2TP
• Firewall
  • Denial-of-service (DoS) attack prevention
• System management
  • NetUSB support
  • Online auto-upgrade firmware
• Others
  • UPnP

Hardare Specifications

• WAN: One 10/100 Mbps Ethernet RJ-45 port with auto MDI/MDIX support
• LAN: Four 10/100 Mbps Ethernet RJ-45 ports with auto MDI/MDIX support
• One USB 2.0 port
• LED indicators
  • Power
  • LAN (1~4)
  • WAN
  • Wireless
  • WPS
  • USB
• Two 2 dBi detachable antennas
• Button
  • Wireless on/off button
  • LED light on/off button
  • WPS button
  • Reset button
• Power: 12 V DC, 1 A
• Power consumption: 8.5 watt max.

Physical Specifications

• Item dimension (W x D xH): 159 x 111 x 23 mm (6.26" x 4.37" x 0.91 ")
• Item weight: 230 g (0.51 lb.)
• Packing dimension(W x D xH): 272 x 60 x 194 mm (10.70" x 2.36" x 7.63")
• Packing weight: 660 g (1.47 lb.)

Environmental Specifications

• Operating environment:
  • Temperature: 0°C to 40°C (32°F to 104°F)
  • Humidity: 10% to 90% (Non-condensing)
• Storage environment:
  • Temperature: -30°C to 70°C (-22°F to 158°F)
  • Humidity: 10% to 95% (Non-condensing)

Certification

• Safety: CE LVD
• EMC: CE, FCC

Package Contents

• Wireless router
• Two detachable antennas
• Power adapter
• Ethernet cable
• Quick start guide
• Warranty card
• Support CD
